TaKAI Series Inductive Ignition System, Single Channel Inductive Ignition Module
IGN84X

30 ampere continuous, 50 ampere burst output, 200mJ energy output per channel (800mJ total)

The quad channel TaKAI ignition module is an exceptional performance, high current, inductive ignition unit using some of the most efficient components available and are ideal for stand alone engine management applications wishing to use high performance 2 wire ignition coils.

TaKAI ignition modules up the ante from our WeaponX lineup which are current limited at 12.5 amperes, and unlike most replacement, or competitor Bosch ignition module units, are not current limited at 7.5amperes. TaKAI ignition modules allow for a continuous 30 ampere output per coil, while allowing for a 80KV coil voltage output.

Using surface mount, MILITARY SPEC SMD technology, TaKAI components are a custom in house solution, are ultra compact, and offer exceptional electronic characteristics over standard industry options.

FEATURES :

Unlimited mileage lifetime warranty*.
-Advanced Mil Spec SMD PCB design.
-80KV coil output capable.
-Continuous 30 ampere, burst 50 ampere current output per coil.
-Mission Ignitions custom ignition drivers are used to ensure intense, no compromise, ignition events which are more resistant to fouling or misfire.
-Thermal protection circuitry.
-Compact size.
-Mission Ignitions EMI / RFI reduction circuitry for stable ECU operation.
-Inductive Flyback protection.
-Splash resistant to standard motorsport fluids
-Internal temperature maximum rating is 180 degrees C (per MIL SPEC)
-MIL SPEC SMD ELECTRONICS

*requires proof of purchase and Mission Ignition Systems provided value files.

WIRING DIAGRAM
TaKAI 4 CHANNEL IGNITOR WIRING DIAGRAM : 4 Channel Inductive Ignition Wiring Diagram.

TECHNICAL SPECIFICATIONS / DATASHEET
Datasheet for electrical parameters, all TaKAI models
TaKAI INDUCTIVE IGNITION SPECIFICATIONS : Full electrical specifications for TaKAI Inductive Ignitor Module.
